EA | EL + Series

EA32G-2H

  • VAP400 (Vestel Android Platform 400)
  • Resolution : 1920x1080 (FHD)
  • Brightness : 350 cd/m2
  • Operation : 16/7
  • Bezel : 21-25 mm (T/R/L), 13-16 mm (B)
  • Interface : HDMI 2.0 / USB / RS232 / RJ45 / Speaker
  • Application Area: Retail
INQUIRY TO BUY
Features
Usb Security

This series lets your USB and your content to be secured within the back cover of the display. The cover is protected with a screw not allowing any outside intervention.

External Device Connections

You may want to connect your teleconference system, screen sharing system, set-top box or external PCs via HDMI port. For this purposes, our monitors help you to maximize user experience with HDMI CEC (Consumer Electronics Control) and HDMI Hotplug capabilities.

Open Platform Support

Our SoC supports API (Application Programming Interface) for solution providers/integrators to develop and integrate any HTML5-based to be installed and used on our displays.

Pixel Shifting

Pixel Shifting is designed to be activated inside the SoC in order to prevent for potential risk of image sticking, caused by constant content. With this feature turned on, pixels on the screen will move in an interval while causing no interference of visual experience.

SoC Content Management

With quad core SoC (System on Chip), this Series displays are the digital signage monitors for both offline designed content and cloud-based managed content. This helps your digital content to be displayed in the displays by content management systems.

Signal Failover

Our SoC Software has a protection for “No Signal” scenario. If the USB is unplugged after your content is set to be displayed with USB, the display will either show your customized banner or search for any other signal from other sources (HDMI, Display Port, etc.). This failover protection is constructed for higher user experience.

Scheduler

Digital Signage Monitor Software allows many important features such as Scheduler. Scheduler sets your display turn on/off time easily and lets you not to worry about the status of your displays in any time.

Subtle Design

This series’ displays exhibit ultra narrow bezel design eliminating the visual superfluities, directing audience focus on your advertised content. This series is found to be desirable for digital signage specific design: internal usb cover, detachable power plug, carrying handles and IR extender.

Usb Auto-Play

You will be able to show photo and video content automatically with USB Auto-play feature. SoC software gives you a choice to turn on USB auto-play function making it easy for end-users to show any media on the screen and not worry about anything else.

Display Control

Digital Signage Display SoC enables the users to control our displays using RS232 commands in a Local Area Network. Together with the full RS232 command list you can change/set volume, turn on/off the monitor, set a schedule for content display, set a webpage link to be displayed and give a wide range of commands in real-time.

Specification Sheet Commercial Datasheet Model Drawing Wall Mount Drawing
Specifications
Display
Screen Size 32"
Panel Technology VA
Backlight Type DLED
Brightness (typical) 350 cd/m²
Native Resolution 1920 x 1080 (16:9) - FHD
Contrast Ratio (typical) 3000:1
Dynamic Contrast Ratio 35000:1
Panel Life Time ( Min. ) 50000 Hrs
Response Time (typical) 8.5 ms
Active Area (H x V) 698.40 x 392.8 mm
Viewing Angle 178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10
Color Value 16.7M
Color Gamut 68% NTSC
Haze Level 3%
Refresh Rate 60 Hz
Orientation Landscape
Operation Hours 16/7
Area of Usage Indoor
Built-in System
Mainboard Model 17MB450VS
Operating System Custom OS (built on Android AOSP)
Memory 2 GB DDR4
Storage 16 GB eMMC
CPU Quad-Core ARM Cortex-A55
GPU ARM Mali-G31 MP2
Wired 10/100 Mbps Ethernet
WiFi WiFi 5 (802.11 a/b/g/n/ac)
HTML5 Browser Vewd
Rear I/Os
Video Input 2xHDMI2.0, 1xUSB-A 3.0, 1xUSB-A 2.0
Video Output 1xHDMI2.0
External Control RS232 (3.5mm jack green), Fast Ethernet (RJ45), Service (RJ12)
Mechanical
Product Dimensions (WxDxH) 734 x 78 x 435 mm
Package Dimensions (WxDxH) 795 x 128 x 530 mm
Product Weight 4.5 kg
Package Weight 6 kg
Vesa Mounting 75 x 75 mm M4
Bezel Width B:21, T/ L/R:14 mm
Environmental Conditions
Operating Temperature 0-40°C
Operating Humidity 10-90%
Power
Power Supply 170 VAC - 240 VAC - 50/60 Hz
Power Consumption
Typical 32 W
Maximum 65 W
Deep Standby ≤0.5 W
Features
Main Features HTML5 CMS Launcher, Android CMS Launcher, Open Content Management Support, Scheduler, USB-Autoplay, Auto-Launch, HDMI-CEC, HDMI-Wakeup, Auto-switch on Failover, Panel Lock, OSD and UI Rotation, Video Rotation, NoSignalPowerOff, Pixel shift, Scheduler, Videowall support, Remote control via LAN, Real Time Clock, SNMP
Mechanical Features Joystick, Fixed IR lens, Rocker Switch, Detachable Power Cable
Speaker 2x6 W
Accessory
Standard QSG, IB, Power cord, Remote control unit, RC battery, Mounting kit, IR extender cable
Certification
Safety Yes
EMC Yes
CE Yes
* Specifications are subject to change without prior notice.
